Brass Cable Gland - Standard Metric & PG Thread (IP68/IP69K Rated)

Common Sizes (Cable Diameter Range)

Materials

• Body: Free-Cutting Brass (IS 319 / C2721 / CuZn39Pb3)
• Sealing Ring: EPDM or Silicone (for high-temp EV applications)
• Clamping Insert: Polyamide 6 (optional metal clamping for heavy-duty)

Thread Types

• Metric (DIN 40430)
• PG (DIN 40430)
• NPT (Optional - for North American standard EV infrastructure)
• BSP (Custom on request)

Protection Rating

• IP68 - Waterproof and dustproof up to 5 bar / 30 mins immersion
• IP69K - High-pressure, high-temp water jet resistance (for EV fast chargers)

Surface Finish Options

• Natural Brass (Machined)
• Nickel Plated (Most common - corrosion and EMI resistant)
• Chrome Plated (Premium EV enclosures)
• Tin Plated (For solder compatibility in battery systems)

Features

• Dome/Hex or Flat Cap types
• Strain relief with multi-clamping range
• Vibration-proof with anti-rotation lock
• Silicone seals for -40°C to +150°C range
• EMI Shielded variants available

Application Areas in EV Sector

• EV Battery Packs - Cable entry for power lines, BMS wiring
• EV Charging Stations - Power and signal cable sealing
• Power Control Units (PCUs) - High current cable management
• EV Motor Controllers - Safe cable routing in high-EMI areas
• Thermal Management Systems - Sealing coolant pump wiring
• Onboard Chargers (OBCs) - Securing and sealing mains input cables
